Note : Due to increasingly high demand, all bicycle sales are subject to vary in shipping/delivery times.
CUP HOLDER
Integrated frame features include built-in cup holder.
REAR RACK
Integrated frame features include the rear rack to carry cargo
U-LOCK FIT
Integrated frame features include built-in U-lock fit.
7-SPEED
Shimano 7-speed drivetrain.
GEOMETRY
| Frame Size | Rider Height | Standover Height |
|---|---|---|
| S | 5’1” to 5’7” | 30.7" |
| M | 5’5” to 5’11” | 31.9" |
| L | 5’9” to 6’3” | 32.7" |
| S | M | L | ||
|---|---|---|---|---|
| A | Seat Tube Length (inch) | 16.9 | 18.9 | 19.7 |
| B | Seat Tube Angle | 73.5° | 73.0° | 72.0° |
| C | Top Tube Length (inch) | 21.7 | 22.4 | 23.2 |
| D | Head Tube Length (inch) | 5.5 | 5.9 | 6.5 |
| E | Head Tube Angle | 71.0° | 71.0° | 71.0° |
| F | Fork Rake (inch) | 1.8 | 1.8 | 1.8 |
| H | Wheelbase (inch) | 40.7 | 41.3 | 41.7 |
| I | Chain Stay Length (inch) | 17.1 | 17.1 | 17.1 |
| J | Bottom Bracket Drop (inch) | 2.4 | 2.4 | 2.4 |
| K | Stack (inch) | 22.2 | 22.6 | 23.2 |
| L | Reach (inch) | 15.1 | 15.5 | 15.7 |
| M | Stand Over Height (inch) | 25.9 | 29.4 | 30 |
| N | Handlebar Width (inch) | 23.6 | 23.6 | 23.6 |
| O | Stem Length (inch) | 3.1 | 3.9 | 3.9 |
| Q | Wheel Size | 700C | 700C | 700C |
Note: In Store Pick Up Only
