Note : Due to increasingly high demand, all bicycle sales are subject to vary in shipping/delivery times.
With an ALUXX SL aluminum frameset that’s engineered with 90mm of rear suspension travel and 100mm up front, this smooth-riding 29er is a master at conquering technical XC terrain. It’s optimized for larger diameter wheels with an updated Maestro suspension system that’s configured for a tighter rear triangle. Its progressive frame geometry makes it quicker and more agile on climbs and descents. A trunnion-mount shock produces a smooth, supple feel with improved pedaling efficiency, and its Advanced Forged Composite upper rocker arm is lighter and stronger than aluminum. A lightweight Giant WheelSystem with Boost technology comes with tubeless tires already set up, making it easy to experience added efficiency and control on technical terrain.
KEY PERFORMANCE FACTORS
XC Efficiency
ALUXX SL aluminum frameset is engineered with lightweight materials and aggressive geometry for faster climbing and accelerating.
29er speed and stability
Frame geometry and suspension are optimized for 29-inch wheels to deliver a race-winning combo of speed and stability on XC terrain.
Traction and control
Updated Maestro Suspension with an Advanced Forged Composite rocker arm and trunnion-mount shock delivers smooth suspension performance on XC climbs, corners and descents.
HIGHLIGHTS
With an ALUXX SL aluminum frameset that’s engineered with 90mm of rear suspension travel and 100mm up front, this smooth-riding 29er is a master at conquering technical XC terrain. It’s optimized for larger diameter wheels with an updated Maestro suspension system that’s configured for a tighter rear triangle. Its progressive frame geometry makes it quicker and more agile on climbs and descents. A trunnion-mount shock produces a smooth, supple feel with improved pedaling efficiency, and its Advanced Forged Composite upper rocker arm is lighter and stronger than aluminum. A lightweight Giant WheelSystem with Boost technology comes with tubeless tires already set up, making it easy to experience added efficiency and control on technical terrain.
ADVANCED COMPOSITE TECHNOLOGY
Giant’s High Performance Grade raw carbon material is used to produce this custom frame material in our own composite factory with a high stiffness-to-weight ratio. The front triangle of these framesets is assembled and molded as one continuous piece in a proprietary manufacturing process called Modified Monocoque Construction.
ADVANCED FORGED COMPOSITE TECHNOLOGY
A state-of-the-art high-pressure molding process is used to produce complex-shaped carbon fiber components that are lighter, stiffer and stronger than similar components made from aluminum. This technology is used in critical performance parts such as Maestro Suspension rocker links.
MAESTRO SUSPENSION TECHNOLOGY
Four strategically positioned pivot points and two linkages all work together to create a single floating pivot for the most active, efficient and independent suspension system on the trail.
OVERDRIVE
Giant’s original oversized fork steerer tube technology. Designed to provide precise front-end steering performance, the system’s oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
TUBELESS SYSTEM
Fewer flat tires. Greater traction. Less rolling resistance and a smoother, faster ride. Giant’s Tubeless System makes it easier than ever to experience all these benefits.
Sizes: S, M, L, XL
Colors: Matte Black/Gloss Charcoal/Gloss Black
Frame: ALUXX SL-Grade Aluminum, 90mm Maestro suspension
Fork: RockShox Recon Silver RL, 100mm, Boost 15x110 QR, 51mm offset, Maxle Stealth, custom tuned for Giant
Shock: RockShox Deluxe Select+, RT, Solo Air, 165/42.5, custom tuned for Giant
Handlebar: Giant Contact SL XC Flat, 31.8
Stem: Giant Contact
Seatpost: Giant Contact, 27.2
Saddle: Giant Contact (neutral), UniClip accessory mount
Pedals: N/A
Shifters: Shimano Deore
Front Derailleur: N/A
Rear Derailleur: Shimano Deore, Shadow+
Brakes: Shimano MT410 hydraulic 4-piston, 180mm
Brake Levers: Shimano MT410
Cassette: Shimano Deore, 12-speed, 10x51
Chain: Shimano
Crankset: Praxis Cadet Boost, 32t
Bottom Bracket: Praxis, press fit
Rims: Giant XCT 29 wheelset, alloy, 25mm inner
Hubs: Shimano Boost [F] 15x110 [R] 12x148, sealed bearing
Spokes: Sapim
Tires: [F] Maxxis Recon Race, tubeless, 29x2.35, foldable, TLR, EXO [R] Maxxis Recon Race, tubeless, 29x2.25, foldable, TLR, EXO
Extras: Tubeless prepared
Weight: The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
SIZING GUIDE AND GEOMETRY
Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.
-
- S 5’4” - 5’8”
-
- M 5’7” - 5’11”
-
- L 5’10” - 6’2”
-
- XL 6’2” - 6’6”
| S | M | L | XL | ||
|---|---|---|---|---|---|
| A | SEAT TUBE LENGTH (inch) | 15.4 | 17.3 | 19.3 | 21.1 |
| B | SEAT TUBE ANGLE | 73.5° | 73.5° | 73.5° | 73.5° |
| C | TOP TUBE LENGTH (inch) | 23.2 | 24 | 24.8 | 25.6 |
| D | HEAD TUBE LENGTH (inch) | 3.7 | 3.7 | 4.1 | 4.5 |
| E | HEAD TUBE ANGLE | 69.0° | 69.0° | 69.0° | 69.0° |
| F | FORK RAKE (inch) | 2 | 2 | 2 | 2 |
| G | TRAIL (inch) | 3.5 | 3.5 | 3.5 | 3.5 |
| H | WHEELBASE (inch) | 43.8 | 44.6 | 45.4 | 46.3 |
| I | CHAIN STAY LENGTH (inch) | 17.2 | 17.2 | 17.2 | 17.2 |
| J | BOTTOM BRACKET DROP (inch) | 1.8 | 1.8 | 1.8 | 1.8 |
| K | STACK (inch) | 23 | 23 | 23.4 | 23.8 |
| L | REACH (inch) | 16.4 | 17.2 | 17.9 | 18.5 |
| M | STAND OVER HEIGHT (inch) | 29.1 | 30 | 31.3 | 32.6 |
| N | HANDLEBAR WIDTH (inch) | 30.7 | 30.7 | 30.7 | 30.7 |
| O | STEM LENGTH (inch) | 2.4 | 2.8 | 3.1 | 3.5 |
| P | CRANK LENGTH (inch) | 6.7 | 6.9 | 6.9 | 6.9 |
| Q | WHEEL SIZE | 29" | 29" | 29" | 29" |
Note: In Store Pick Up Only
